Frameset
- Seat Binder
- Alloy, 38.6mm
- Frame
- M5 alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
- SWAT
- SWAT 4.0 internal downtube storage
Suspension
- Fork
- FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset S1:150mm of travel, S2-S6:160mm of travel
- Rear Shock
- FOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/3 setting Open mode tuning range, LSR adjustment, 210x55mm
Brakes
- Front Brake
- SRAM DB8 Stealth, 4-piston caliper, hydraulic disc, 200mm rotor
- Rear Brake
- SRAM DB8 Stealth, 4-piston caliper, hydraulic disc, 200mm rotor
Drivetrain
- Cassette
- SRAM 12-speed,10-52t
- Chain
- SRAM 70 Transmission 12-Speed Flattop Chain
- Bottom Bracket
- SRAM DUB Threaded Wide
- Shift Levers
- SRAM Eagle 70
- Rear Derailleur
- SRAM Eagle 70 Transmission, 12-speed, easy shift under load
- Crankset
- SRAM Eagle 70, 165/170mm, 55mm chainline, 32T
Wheels & tires
- Front Tire
- Butcher, GRID TRAIL casing, Gripton T9 compound, TLR, 29X2.4
- Spokes
- DT Swiss Elemental
- Rear Tire
- Eliminator, GRID TRAIL casing, Gripton T7 compound, TLR, S1-S2: 27.5x2.4, S3- S6: 29x2.4"
- Front Hub
- Sealed cartridge bearings, 6-bolt, 15x110mm thru-axle, 28h
- Rear Hub
- Specialized alloy rear hub disc, sealed cartridge bearings, 6-Bolt, 12X148mm thru-axle, 32h, HG Steel Fhb
- Rims
- Specialized, hookless alloy, 30mm inner width, tubeless ready
- Inner Tubes
- Standard, Presta Valve
Cockpit
- Stem
- Alloy Trail Stem, 35mm bar bore
- Saddle
- Bridge Comp, Hollow Cr-mo rails 155/143
- Grips
- Specialized Trail Grips
- Handlebars
- Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S6: 800 width, 50mm rise
- Seatpost
- Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 190mm
Product details
- Product ID
- 263530
Weight
- Weight
- 16.69 kg (36 lb, 12.7 oz)
- Weight Size
- S4
