Frameset
- Seat Binder
- Alloy, 38.6mm
- Frame
- M5 alloy chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
- SWAT
- SWAT 4.0 internal downtube storage
Suspension
- Fork
- All New SRAM Rockshox Lyrik Ultimate, 29" 160mm (S2-S6); 150mm (S1), LinearXL air spring with ButterCups and adjustable bottom out, new Charger 3.2 damper with HSC and LSC, rebound adjust
- Rear Shock
- All New Rockshox Super Deluxe Select GENIE, GENIE adjustable airspring, rebound adjust, 210x55mm
Brakes
- Rear Brake
- SRAM Maven Ultimate B1, 4-piston caliper, hydraulic disc, 200mm rotor
- Front Brake
- SRAM Maven Ultimate B1, 4-piston caliper, hydraulic disc, 200mm rotor
Drivetrain
- Cassette
- SRAM 12-speed,10-52t
- Shift Levers
- SRAM 90 trigger, 12-speed, single click
- Bottom Bracket
- SRAM DUB Threaded Wide
- Rear Derailleur
- SRAM Eagle 90 T-Type
- Crankset
- SRAM Eagle 90, S1-S3: 165mm, S4-S6: 170mm, 55mm chainline, 32T
- Chain
- SRAM GX Eagle Transmission 12-Speed Flattop Chain
Wheels & tires
- Front Tire
- Butcher, GRID TRAIL casing, Gripton T9 compound, TLR, 29X2.4
- Rear Tire
- Eliminator, GRID TRAIL casing, Gripton T7 compound, TLR, S1-S2: 27.5x2.4, S3- S6: 29x2.4"
- Front Wheel
- Roval Traverse Rim 29", hookless alloy, 30mm inner width, tubeless ready, DT Swiss 370 Hub, 15x110mm, 28h, Sapim Force Spokes
- Rear Wheel
- Roval Traverse Rim, hookless alloy, 30mm inner width, tubeless ready, DT Swiss 370 Hub, 15x110mm, 28h, Sapim Force Spokes, S1-S2: 27.5", S3:-S6: 29"
- Inner Tubes
- Standard, Presta Valve
Cockpit
- Stem
- Specialized, 35mm Clamp, 35mm Reach
- Saddle
- Bridge Comp, Hollow Cr-mo rails 155/143
- Grips
- Deity Supracush, Lock On, 34mm OD, 133mm Length, Black
- Handlebars
- Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S6: 800 width, 50mm rise
- Seatpost
- Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 190mm
Product details
- Product ID
- 263531
Weight
- Weight
- 16.79 kg (37 lb, 0.2 oz)
- Weight Size
- S4
