The Quake is made for the biggest sends, the wildest lines and the highest speeds Read more..
The Quake is made for the biggest sends, the wildest lines and the highest speeds. The Series 4 Aluminum frame soaks it all up without breaking a sweat – adjustable geometry and 180mm of MultiTrac 2 suspension help you dial it to any track, any condition, any ambition. RockShox’s legendary Boxxer fork and Vivid shock, SRAM’s powerful Maven brakes, GX DH drivetrain and Schwalbe’s grippy radial casing tires complete the jaw-dropping spec.
This is what invincible feels like.
The Quake starts with one goal: be the perfect big bike.
The all-new Series 4 alloy frame is engineered to handle the most demanding tracks on earth – from bike park laps to Darkfest, Red Bull Hardline or Rampage – without compromise. Adjustable geometry and chainstay length mean you can dial the Quake to any track, any condition and run mullet or full 29.
Matt Jones, Janelle Soukup, Mark Matthews, Vinnie Moonen, Arlie Connelly – our team riders can’t get enough of the Quake’s ride. Red Bull Rampage, Hardline, Darkfest and the Freeride Fiesta – it hits them all.
At its heart is our MultiTrac 2suspension design. 180mm of rear wheel travel is tuned to be uncompromising – big hit control keeps you composed through the nastiest chunk, while DH bike small bump compliance means you stay connected and in control through the rough. We’ve dialed the pop to travel ratio – it’s ready to send and cushion the landing.
The RockShox Vivid Coil Ultimate DH shock is custom-tuned to work in perfect harmony with the MultiTrac 2 kinematics. Specific spring rates for S, M and L make the bike feel right from the first run.
There are no trade-offs, only the whole package.
The spec matches its ambition. RockShox's Boxxer fork and Vivid Coil Ultimate DH shock are the gold standard in gravity suspension. SRAM Maven Silver four-piston brakes are the yin to every steep trail's yang – pure stopping power when you need it most.
A mixed wheel setup – 29in front for rollover and momentum, 27.5in rear for agility and clearance – blends the best characteristics. Schwalbe Magic Mary Gravity Radial tires have maximum traction – Ultra Soft compound up front for pure grip, Soft rear for speed and control. Whatever the conditions throw at you, the Quake eats it up.
The mountain doesn't stand a chance.
SPEC AND PRICE BEING SUBJECT TO CHANGE WITHOUT NOTIFICATION
All New Series 4 Alloy, 180mm MultiTrac LT Suspension, Adjustable CS Length/Height, 27.5" or 29" compatible, 148mm Rear Thru-Axle, & frame protection, UDH
Rock Shox Boxxer, 200mm Travel, 29" , 110x20mm Maxle Stealth, 52mm Offset
Rock Shox Vivid Coil Ultimate DH, 225x75mm Trunnion Upper Mount, 30xM8 Lower Mount, Custom Tune, S = 350 lb/in / M = 450 lb/in / L = 550 lb/in
New Marin DH Rim, Double Wall Alloy, 29mm Inner, Sleeved Joint, Disc Specific, 32H, Tubeless Compatible
Formula, DDL-348S, 148x12mm, 6-Bolt Disc, 32H, Shimano Freehub Body
Marin Forged, 110x20mm, 6-Bolt Disc, 32H
14g Black Stainless Steel
Front: Schwalbe Magic Mary, Gravity Pro, 29x2.5", Radial, Ultra Soft Rear: Schwalbe Magic Mary, Gravity Pro, 27.5x2.5", Radial, Soft
e*thirteen Vario DH Chainguide
Sram GX DH
Sram GX DH, 7-Speed
Sram Descendant Alloy 34T, 165mm
Sram DUB BSA
Sram PC-1110
GS DH, 11-15T
SRAM Maven Silver, 4-Piston Hydraulic Disc, HSC 200mm Rotor
SRAM Maven Silver, 4-Piston Hydraulic Disc, HSC 200mm Rotor
SRAM Maven Silver
PNW Range Handlebar, 38mm Rise, 35mm Clamp, 800mm Width
Marin Direct Mount Stem, 35mm Length, 35mm Clamp
Marin Grizzly Lock-On
FSA No 74
Marin Alloy, 34.9mm
Marin Short Nose
Downtube & Shuttle Guards
